GDFR-1100+G+SThree-Line T-Shirt Bag Making Machine with Hot Slitting & Side Gusset - Full Automatic High Speed Three Lines T-shirt Making Machine With Hot Slitting and Side Gusseting Unit

Watch The Video

GDFR-1100+G+SThree-Line T-Shirt Bag Making Machine with Hot Slitting & Side Gusset

The GDFR-1100+G+S is a fully automatic three-line T-shirt bag making machine with inline hot slitting and a side gusset unit. It splits a single jumbo roll into multiple lines for high-output production of gusseted vest-handle bags, running HDPE, LDPE, and biodegradable PLA/PBAT films at up to 250 pcs/min per cycle.

Max. Bag Width

300mmX3

Producing Length

300-700mm

Max. Producing Speed

250pcs/min

Main Technical Parameters

Model	GDFR-1100
Max. Bag Width	300 mm × 3
Producing Length	300–700 mm
Max. Producing Speed	250 pcs/min
Film Thickness	0.010–0.040 mm
Suitable Materials	HDPE / LDPE / PLA / PBAT
Total Power	16 kW
Max. Film Roll Diameter	850 mm
Max. Film Roll Width	1400 mm

Performance and Features

Special designs of 3 lines vest handle T-Shirt bag by slit one jumbo roll into two lines and inline side gusset. Operating in fully automatic system includes automatic EPC deviation rectification control system, automatic speed and tension control by dancer cylinders system, and swing arm tension control servo boost unwinding system. Exclusive patent design of hot cutting and hot sealing method for several materials which includes HDPE, LDPE, PLA, and PBAT (biodegradable).

Multiple automatic alarms with auto-stop protection.
Built-in multi-language HMI: Chinese, English, Spanish, Arabic, Russian, and Turkish.
Patented cutting-and-sealing knife for HDPE, LDPE, PLA, and biodegradable PBAT films.
"Rocking System" keeps the full pile of bags from sticking at the sealed edge.
Inline automatic punching unit with folding device and automatic waste collection.
Built-in inline hot-slitting and side-gusset device with automatic speed and tension control.

Manufacturing Process

From raw film to finished T-shirt bag — a fully automated 7-stage production line with inline slitting and gusset

Unwinding

Feeds jumbo film from the unwind stand with tension control and EPC tracking for stable, wrinkle-free material supply.

Hot Slitting

Slits a wide jumbo roll into multiple narrow lanes inline before bag forming begins.

Air Inflation

Inflates the tubular film to open side folds and prepare the web for gusset forming.

Gusset

Forms side gussets by folding the inflated film inward, adding depth to the bag body.

Hot Sealing & Hot Cutting

Heat-seals the bag body and cuts individual bags in one synchronized pass for clean, strong edges.

Die Cut

Punches the vest-style handle opening and trims the bag profile with a precision die.

Folding

Automatically stacks and folds finished bags for neat collection and downstream packing.
