Computer Control Side Sealing & Hot Cutting Bag Making Machine

BF-650/800/1000/1200 Computer Control Side Sealing & Hot Cutting Bag Making Machine is ideal for heat-sealing and cutting various films. It produces normal, pillow, and envelope-type bags.
Max. Producing Width (Bag Length)

50-60mm

Producing Length (Bag Width)

100-600mm

Max. Producing Speed

30-140pcs/min

Performance and Features

It is suitable for heat-cutting & heat-sealing all kinds of natural color films and color films such as: BOPP, OPP, PE etc. It can make normal type, pillow type and envelope type.

  1. The main motor adopts frequency conversion motor to adjust the speed.
  2. It adopts microcomputer to control, servo motor to pull material, which will accurate the sealing and cutting location .Automatic counting and settable counting alarm .The machine will stop automatically when the color mark is lost.
  3. Feeding by DC motor and film potentiometers add the synchronization between feeding and main motor .
  4. The sealing and cutting blade are a kind of special tool steel, uneasy deformation.
  5. The conveyor belt adopts the imported driven strap and DC motor to adjust the speed, which make the process of receiving bags steady and reliable.
  6. It adopts pneumatic equipment to punch. Rubberizing simultaneously.

Applications & Industries We Serve

Every Lingfeng plastic bag making machine is built around a real production goal. Below are the most common bag types and industries this equipment serves — from high-volume retail to specialized, eco-friendly formats. Tell us your application and our engineers will match the right machine configuration.

Manufacturing Process

Standard side seal bag — folding and side sealing & cutting
Unwinding
01
Unwinding
Folding
02
Folding
Side Sealing and Cutting
03
Side Sealing & Cutting

Main Technical Parameters

Model BF-650 BF-800 BF-1000 BF-1200
Max. Producing Width (Bag Length) 50-60mm 70-600mm 80-600mm 80-700mm
Producing Length (Bag Width) 100-600mm 150-750mm 150-950mm 150-1150mm
Max. Producing Speed 30-140pcs/min 30-120pcs/min 30-100pcs/min 30-100pcs/min
Film Thickness 0.010-0.100mm 0.010-0.100mm 0.010-0.100mm 0.010-0.100mm
Total Power 4.5kW 5kW 5.5kw 7KW
Weight 1100kg 1300kg 1400kg 1600kg
